Before fixing the regulator on the LP gas cylinder valve, Read the instruction carefully.
The regulator is designed for using with Propane/Butane/ or any mixture of these gas types.
In normal conditions of use, in order to ensure a correct operating of the installation, it is recommended that this regulator is changed within 10 years of the date of production.
When the regulator is to be used outdoors, it shall be positioned or protected against direct penetration by any strickling water.
Make sure that the consumer seal on the valve is in good condition.
Do not move the cylinder during the operation.
Also take into consideration of your regional standards and rules.
Make sure that tall taps and appliances are turned off.
Do not change the LP gas cylinders in the presence of open lights and flames.
Use LP gas cylinders in upright position only.
Make sure that the installed flexible gas tubing is still in good condition and not more than 3 years old.
Step-by-Step Operating Instructions
1
Before connecting the regulator on the cylinder valve, turn the switch to off position. (the flame is marked with X).
2
And place the regulator on the cylinder valve.
3
Push the bottom ring strongly down. There will be a clear click. Hold the regulator in both hands. Lift the bottom ring.
4
Make sure that the regulator is properly fixed on the valve. Try to pull the regulator upwards. If the regulator comes off the valve, please repeat the step 2 and 3.
5
To operate the regulator, turn the switch to the “ON" position. (the flame is upwards). Always turn the switch to "off" position after use.
6
To disconnect the regulator from the cylinder valve, turn the switch to "Off" position. Then lift the bottom ring and remove the regulator.
Frequently Asked Questions (FAQ)
What gas types can be used with this regulator?
The regulator is designed for use with Propane, Butane, or any mixture of these gas types.
How often should the regulator and flexible gas tubing be replaced?
Under normal operating conditions, it is recommended to replace the regulator within 10 years of the production date. The flexible gas tubing must be in good condition and replaced if it is more than 3 years old.
How can I verify that the regulator is securely attached to the valve?
After pushing the bottom ring down until you hear a clear click, try pulling the regulator upwards. If it comes off, repeat the connection process to ensure proper fixing.
What precautions should I take when using the gas cylinder outdoors?
When positioned outdoors, the regulator should be protected against direct penetration by any trickling or strickling water.
What are the key safety requirements when changing or operating the LP gas cylinder?
Never change gas cylinders in the presence of open lights or flames. Always keep cylinders in an upright position, ensure tall taps and appliances are turned off, and do not move the cylinder while it is operating.
